Features:
Constant current mode
Output SELV protection, short circiut, over current and over voltage protection
Extremely high precision current
High power factor
Standards：
TUV EN60950-1 EN61347-2-13 EN55015 EN55022(CISPR22) EN61000-3-2
EN61000-3-3 EN61000-4-2 ENV50204 EN55024
Specification:
| Models | Input Volatge (V) | P.F. | Output Voltage (V) | Output Current (mA) | Output Power (W) | Dimension L*W*H (mm) |
| SILH57035BG5 | 220-240Vac | 0.9 | 34-57V | 350mA | 13-20W | 103*53.5*14 |
| SILH38040BG5 | 20-38V | 400mA | ||||
| ... | ... | ... | ||||
| SILH28070BG5 | 17-28V | 700mA |
P.S.: The current step is 50mA, contact us for the specs outside of above tables.
Application：
