Description:
Specification:
| Model | HK-30 Vario | HK-30L Vario |
| End Milling Capacity | 25mm | |
| Face Milling Capacity | 80mm | |
| Drilling Capacity | 32mm | |
| Spindle Taper | MT3 or R8 | |
| Spindle travel | 70mm | |
| Spindle speed | 50-2250rpm | |
| Head Rotation | up/down 45 degree | |
| Work table size | 700*210mm | 840*210mm |
| X-axis Travel | 425mm | 565mm |
| Y-axis Travel | 220mm | |
| Z-axis Travel | 360mm | |
| T-slot dimension | 14mm | |
| Motor power | 1100W | |
| Packing dimension (L*W*H) | 710*890*1150mm | 850*890*1150 |
| N.W./G.W. | 220/250kg | 240/275kg |
