Features:
Constant current mode
Output SELV protection, short circiut, over current and over voltage protection
Extreamely high precision current;
Dimming range: 3%-100%
High power factor
Dimming mode: stepless adjusted or single adjusted
Standards:
TUV EN60950-1 EN61347-2-13 EN55015 EN55022(CISPR22) EN61000-3-2
EN61000-3-3 EN61000-4-2 ENV50204 EN55024
Specification:
Model | Input voltage (V) | P.F. | Output Voltage (V) | Output Current (mA) | Output Power (W) | Dimension L*W*H (mm) |
SIAH85035BG3 | 220-240Vac | 0.95 | 65-85V | 350mA | 21-30W | 114*71.5*30 |
SIAH75040BG3 | 52-75V | 400mA | ||||
... | ... | ... | ||||
SIAH30A00BG3 | 21-30V | 1000mA |
P.S.: The current step is 50mA, contact us for the specs out of above tables.
Application:
